Specificaties:
Mfr Package Description SODIMM-204
REACH Compliant Yes
EU RoHS Compliant Yes
Status Active
Access Mode SINGLE BANK PAGE BURST
JESD-30 Code R-XZMA-N204
Memory Density 3.4359738368E10 bit
Memory IC Type DDR3 DRAM MODULE
Memory Width 64
Number of Functions 1
Number of Ports 1
Number of Terminals 204
Number of Words 5.36870912E8 words
Number of Words Code 512M
Operating Mode SYNCHRONOUS
Operating Temperature-Min 0.0 Cel
Operating Temperature-Max 85.0 Cel
Organization 512MX64
Package Body Material UNSPECIFIED
Package Code DIMM
Package Shape RECTANGULAR
Package Style MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Cel) 260
Seated Height-Max 30.13 mm
Self Refresh YES
Supply Voltage-Nom (Vsup) 1.5 V
Supply Voltage-Min (Vsup) 1.425 V
Supply Voltage-Max (Vsup) 1.575 V
Surface Mount NO
Technology CMOS
Temperature Grade OTHER
Terminal Form NO LEAD
Terminal Pitch 0.6 mm
Terminal Position ZIG-ZAG
Time@Peak Reflow Temperature-Max (s) 20
Length 67.6 mm
Width 3.37 mm
Additional Feature AUTO/SELF REFRESH; WD-MAX
